紧凑型封装
低饱和压降
PCB组装
集成负温度系数传感器
氧化铝绝缘衬板
电机传动
空调
辅助逆变器
| TYPE | INVERTER | BRAKE | RECTIFIER | Package | Technology | |||||||
| VCES Volts | IC Amps | VCE(SAT) Volts | Ptot Watts | VCES Volts | IC Amps | VCE(SAT) Volts | VRRM Volts | IO Amps | VF Volts | |||
| LWP50H12E4-7M | 1200V | 50A | 1.65V | 280W | 1200V | 35A | 1.85V | 1600V | 35A | 1.30V | ECPIM 3a | Trench FS |
| LWP75H12E4-7M | 1200V | 75A | 1.65V | 385W | 1200V | 50A | 1.65V | 1600V | 50A | 1.30V | Trench FS | |
| LWP100H12E4-7M | 1200V | 100A | 1.65V | 515W | 1200V | 75A | 1.65V | 1600V | 60A | 1.30V | Trench FS | |
| LWP50H12R4-7M | 1200V | 50A | 1.70V | 280W | 1200V | 35A | 1.85V | 1600V | 35A | 1.30V | Trench LPT | |
| LWP75H12R4-7M | 1200V | 75A | 1.70V | 385W | 1200V | 50A | 1.70V | 1600V | 50A | 1.30V | Trench LPT | |
| LWP100H1C4-7M | 1200V | 100A | 1.70V | 515W | 1200V | 75A | 1.65V | 1600V | 60A | 1.30V | Advance Trench FS | |
| LWP50H12E4-7B | 1200V | 50A | 1.65V | 280W | 1200V | 35A | 1.85V | 1600V | 35A | 1.30V | ECPIM 3b | Trench FS |
| LWP75H12E4-7B | 1200V | 75A | 1.65V | 385W | 1200V | 50A | 1.65V | 1600V | 50A | 1.30V | Trench FS | |
| LWP100H12R4-7B | 1200V | 100A | 1.65V | 515W | 1200V | 75A | 1.65V | 1600V | 60A | 1.30V | Trench FS | |
