LWG150H12S4L

  • 低饱和压降

  • 10μs 短路电流

  • 低关断损耗

  • 正温度系数

  • 快速软恢复FRD

  • 铜底板标准封装

产品应用

  • 电焊机

  • 感应加热

  • 电镀电源

  • 等离子切割机

内部电路图

规格参数

TYPEVCESVGESICVCE(SAT)(EON+EOFF)TJPtotCircuitPackageTechnology
VoltsVoltsAmpsVoltsmJWatts
LWG100H12S4L1200V ± 20100A2.80V24.7mJ150℃560W2 Pack62mmNPT
LWG150H12S4L1200V ± 20150A2.80V32.8mJ150℃820W2 Pack
LWG200H12S4L1200V ± 20200A3.10V41.0mJ150℃1100W2 Pack
LWG300H12S4L1200V ± 20300A3.10V56.0mJ150℃1600W2 Pack
LWG100H12E4L1250V ± 30100A1.65V31.2mJ175℃517W2 PackTrench FS
LWG150H12E4L1250V ± 30150A1.65V39.2mJ175℃750W2 Pack
LWG200H12E4L1250V ± 30200A1.65V48.0mJ175℃1071W2 Pack
LWG300H12E4L1250V ± 30300A1.65V66.0mJ175℃1363W2 Pack
LWG400H12E4L1250V ± 30400A1.65V89.0mJ175℃2050W2 Pack
LWG100H12W4L1200V ± 20100A2.25V24.7mJ175℃560W2 PackTrench
fast
LWG150H12W4L1200V ± 20150A2.00V32.8mJ175℃750W2 Pack
LWG200H12W4L1200V ± 20200A2.00V41.0mJ175℃1071W2 Pack
LWG300H12W4L1200V ± 20300A2.00V56.0mJ175℃1363W2 Pack
LWG400H12W4L1200V ± 20400A2.00V75.0mJ175℃2050W2 Pack
