紧凑型设计
低饱和压降
低电感设计
集成负温度系数传感器
可提供扁平和针翅状底板
汽车应用
混合动力电动汽车
电机驱动
商用农用车
| TYPE | VCES Volts | VGES Volts | IC Amps | VCE(SAT) Volts | (EON+EOFF) mJ | TJ | Ptot Watts | Circuit | Baseplate type | Package | Technology |
| LHG820S08B7P1 | 750V | ± 20 | 820A | 1.30V | 37.0mJ | 175℃ | 714W | 6 Pack | PinFin | HP7 | Trench FS |
| LHG950S08B7P1 | 750V | ± 20 | 950A | 1.30V | 42.5mJ | 175℃ | 870W | 6 Pack | PinFin | ||
| LHG400S12B7P1 | 1250V | ± 20 | 400A | 1.65V | 37.5mJ | 175℃ | 870W | 6 Pack | PinFin | ||
| LHG400S07B6F1 | 650 | ± 30 | 400A | 1.90V | 14.2mJ | 175℃ | 1250W | 6 Pack | Flat | HP6 | |
| LHG400S07B6P1 | 650 | ± 30 | 400A | 1.90V | 14.2mJ | 175℃ | 811W | 6 Pack | PinFin |
