紧凑型封装
低饱和压降
PCB组装
集成负温度系数传感器
氧化铝绝缘衬板
电机传动
空调
辅助逆变器
| TYPE | INVERTER | BRAKE | RECTIFIER | Package | Technology | |||||||
| VCES Volts | IC Amps | VCE(SAT) Volts | Ptot Watts | VCES Volts | IC Amps | VCE(SAT) Volts | VRRM Volts | IO Amps | VF Volts | |||
| LMP10H12E4-7M | 1200V | 10A | 1.95V | 105W | 1200V | 15A | 2.00V | 1600V | 16A | 1.30V | EZPIM 1B | TrenchFS |
| LMP15H12E4-7M | 1200V | 15A | 2.00V | 130W | 1200V | 15A | 2.00V | 1600V | 16A | 1.30V | TrenchFS | |
| LMP15H12L4-7M | 1200V | 15A | 1.70V | 130W | 1200V | 15A | 1.70V | 1600V | 15A | 1.20V | TrenchFS,Low loss | |
| LMP25H12E4-7M | 1200V | 25A | 2.00V | 155W | 1200V | 25A | 2.00V | 1600V | 25A | 1.30V | TrenchFS | |
| LMP25H12E4-7B | 1200V | 25A | 2.00V | 175W | 1200V | 25A | 2.00V | 1600V | 30A | 1.20V | EZPIM 2B | TrenchFS |
| LMP35H12E4-7B | 1200V | 35A | 1.90V | 215W | 1200V | 25A | 1.90V | 1600V | 30A | 1.20V | TrenchFS | |
| LMP25H12L4-7B | 1200V | 25A | 1.70V | 175W | 1200V | 25A | 1.70V | 1600V | 25A | 1.20V | TrenchFS,Low loss | |
| LMP35H12L4-7B | 1200V | 35A | 1.75V | 215W | 1200V | 35A | 1.75V | 1600V | 35A | 1.20V | TrenchFS,Low loss | |
| LMP40H12E4-7B | 1200V | 40A | 1.75V | 258W | 1200V | 25A | 1.90V | 1600V | 35A | 1.20V | TrenchFS,Low loss | |
